Saxophone

The straight soprano and sopranino saxophones consist of a straight conical tube with a flared bell at the end opposite the mouthpiece. Alto and larger saxophones include a detachable curved neck above the highest tone hole, directing the mouthpiece to the player's mouth and, with rare exceptions, a U-shaped bow that directs the bore upward and a curve in the throat of the bell directing it forward. The set of curves near the bell has become a distinctive feature of the saxophone family, to the extent that soprano and even sopranino saxes are sometimes made in the curved style. The baritone, bass, and contrabass saxophones accommodate the length of the bore with extra bows and right-angle bends between the main body and the mouthpiece.

The left hand operates keys from the upper part of the body tube while the right hand operates keys from the lower part. The right thumb sits under a thumb hook and left thumb is placed on a thumb rest to stabilize and balance the saxophone, while the weight of most saxophones is shared by the right thumb and a neckstrap attached to a strap ring on the rear of the body of the instrument. With the smaller instruments, relatively more of the weight is supported by the thumb. The left thumb operates the octave key.

Keys consist of the cups, levers, and pivots that control the position of the pads over the toneholes. At rest, some keys are open and some are closed, held in position by springs that are overridden by finger or hand (palm keys) pressure. The keys are activated by pressure on key touches, either directly on the pad cup or connected to it with levers, either directly or with joints called linkages. The levers between the key cups and the pivots are called key arms.

The fingering for the saxophone is a combination of that of the oboe with the Boehm system and is similar to the flute or upper register of the clarinet.
